AEWW036

Mini 2.4G WiFi Rubber Antenna | WiMAX Bluetooth, and Zigbee Monopole Extreme Low Profile

WIFI/Bluetooth/ISM

Single External Antennas

Download

Datasheet

Buy Samples

Coming soon

Dealers

Coming soon

Aboosty is ready to help you tackle various wireless issues.

Mini 2.4G WiFi Rubber Antenna | WiMAX Bluetooth, and Zigbee Monopole Extreme Low Profile

Our 5G antennas offer an extreme boost to speed and significantly lower latency, whilst also boasting greater bandwidth.

Product Overview

Key Features

Description

Specification

Applications

Peak Gain: 2.38 dBi

Straight type with built-in SMA-Male connector

Monopole, ground plane dependent

Compact and lightweight, ideal for small digital devices

Waterproof and dustproof, durable in harsh environments

Stable performance, low attenuation, anti-jamming

Custom connectors available

RoHS Compliant

Operating Frequency: 2400-2500 MHz
Dimensions: Ø9.3 x 27.8 mm

The Aboosty AEWW036 is a direct mount 2.4 GHz WIFI, Bluetooth antenna designed to be mounted directly onto a device. This Omni-Directional Antenna with RF SMA plug connector is made from durable material – reinforced plastic and copper wire. A professional, durable accessory!

The connector is customizable subject to NRE and MOQ. For further information, don’t hesitate to get in touch with the Aboosty customer support team.

LABEL

VALUE

Certificates Acquired

RoHS Compliant

Length (mm)

Ø9.3

Width (mm)

Height (mm)

27.8

Freq. (MHz)

2400-2500

Technology Type

2.4G WIFI, Bluetooth, Zigbee

Frequency Bands

2.4 GHz

Operating Temperature (℃)

-40°C to +85°C

Markets

Smart Industrial, Smart Cities, Mobile Communication

Antenna Type

Monopole

Connector Style

Straight

Radiation Pattern

Omnidirectional

Polarity

Linear

Max Effi. (%)

43.54

Peak Gain

3.01 dBi

VSWR

3.0:1

Impedance (Ω)

Ingress/Impact

N/A

Termination Style

Connector

Antenna Connector Type

SMA-Male

Cable Type

N/A

Cable Length (mm)

N/A

Mechanical Style

Whip/Stick

Mounting Style

Connector Mount, Direct Mount

Customization Option

Logo, Packaging

Smart Home Devices
IoT Systems
IoT Devices
Wireless Sensors
Bluetooth Devices
Home Automation Systems

Part Number

User Story

Model

Description

Note

AEWW036

Mini2.4G WIFI Antenna with SMA-Male Connector

M02-0600220R0A

Customization supported
